Phoenix Contact 1604638 Panel-mount flange HC-B-AF-SET
Normally In Stock
Code: 238769
Phoenix Contact 1604638 - Panel-mount flange, Set of 2 with screws - Nut Locking
Condition: New
Usually ships Same Day or Next Day$6.12
Sale Price
$5.10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1604638 For a HEAVYCON ADVANCE housing from the Heavycon series, you'll need a panel-mount flange set that includes two pieces: each piece has four self-tapping M4 Torx screws along with four fan-type washers.
Specifications
Component
Panel
Connector Material
Die-Cast Aluminum
Manufacturer
Phoenix Contact
Sub Component
Flange
Features
The right connection for your requirements every time with three different series
Compatible connection: housings and contact inserts are mounting and plug-in compatible with solutions from well-known manufacturers
Flexible combination: variable connection technologies for contact inserts and terminal adapters
Customized, compact interface: combine modular contact inserts for signals, data, power, and pneumatics in one connector
Protection against electromagnetic interference: metal housings are EMC-ready due to their conductive surfaces and seals
Downloads
2d view of the application.dxf3d view of the application.stpProduct Specification.pdfpxc_1604638_09_01_HC-B-AF-SET_APP2D_B10.dxfpxc_1604638_09_01_HC-B-AF-SET_APP2D_B24.dxfpxc_1604638_09_01_HC-B-AF-SET_APP3D_B10.stppxc_1604638_09_01_HC-B-AF-SET_APP3D_B16.stppxc_1604638_09_01_HC-B-AF-SET_APP3D_B24.stppxc_1604638_09_02_HC-B-AF-SET_APP2D_B06.dxfsimplified 3d model of the item.stp
