Phoenix Contact 1039563 Connector QPD P 4PE2,5 6-11 TL BK
Normally In Stock
Code: 235877
Phoenix Contact 1039563 - Connector - 5 Positions - Cu - 16 AWG - 20 Amp - 690 V - IP66 - Screw Locking
Condition: New
Usually ships Same Day or Next Day$17.23
Sale Price
$14.36
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1039563 A connector product within the QPD family features an IDC connection and can accommodate up to 4 positions for push-pull electrical contacts, ranging in size from 1mm2 to 2.5mm2, rated at 690V and 20A of current, with a black colour scheme and a QUICKON nut, while its external cable has a diameter of approximately 6mm to 11mm.
Specifications
Connector Amperage
20 Amp
Connector Material
Cu
Connector protection
IP66
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
5
Sub Component
Installation Connector
Connector Voltage
690 Volt
Features
Innovative and time saving - QUICKON fast connection for time saving of up to 80 % for on-site connection
Robust throughout: housing with IP68/IP69K and IK07 protection for a wide range of applications
Safer connection with mechanical coding to protect against mismatching, and touch-proof protection in accordance with DIN EN 0105
Easy maintenance – the connectors enable fast device replacement and preassembled cables simplify startup
