Phoenix Contact 1014498 Connector PRC 3-FC-MS6 8-21
Normally In Stock
Code: 235823
Phoenix Contact 1014498 - Connector - 3 Positions - Cu Alloy - Black - 35 Amp - IP66 , IP68 - Screw Connection - Snap-In Locking
Condition: New
Usually ships Same Day or Next Day$18.20
Sale Price
$15.17
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1014498 The connector is available in a range of options with a minimum conductor cross section of 1.5mm² and a maximum of 6mm², it comes in black color and has three positions for connection. It features screw connections with pin-type contacts, suitable for cables with diameters between 8mm to 21mm, ensuring touch protection against voltage up to 690V AC and current capacity of 35A.
Specifications
Connector Color
Black
Connector Amperage
35 Amp
Connector Material
Cu Alloy
Connector Material
EPDM
Connector protection
IP66
Connector protection
IP68
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
3
Sub Component
Installation Connector
Features
Up to 75% smaller in size than industrial connectors with the same rating
Locking mechanism can be unlocked manually or using a tool
Suitable for applications in atmospheres containing salt and in direct sunlight
Ideal for indoor and outdoor use due to weatherproof materials
