nVent Hoffman A48HS3612GQRLP Non-Metallic Fiberglass Disconnect Enclosure
Normally In Stock
Code: 16236
nVent Hoffman A48HS3612GQRLP Fiberglass Disconnect Enclosure. 48" x 36" x 12" (HxWxD). Fiberglass Type 4x with quarter-turn latches and standard hinges. Includes bracket affixed to door for attaching disconnect door catch (interlock) and instructions for installing disconnects. (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$5312.80
Sale Price
$4427.33
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
nVent Hoffman A48HS3612GQRLP Non-Metallic Fiberglass Disconnect Enclosure nVent Hoffman A48HS3612GQRLP Fiberglass Disconnect Enclosure. 48" x 36" x 12" (HxWxD) This nVent Hoffman Fiberglass Type 4x enclosure is made for the harshest corrosive environments. With a fiberglass-reinforced material, a seamless foam-in-place gasket, a high-impact thermoplastic data pocket, and sealed seams, this enclosure is sure to protect enclosed components from water, dust, and other contaminants. Type 304 stainless steel slotted quarter-turn latches ensure security. Material that is easily drilled, filed or sawed adds versatility to this durable nVent Hoffman enclosure.
Specifications
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Hinge Type
Standard Hinge
Enclosure Latch Type
Quarter Turn
Enclosure Depth
12"
Enclosure Interior Color
Gray
Enclosure Composition
Fiberglass
Enclosure NEMA Rating
NEMA Type 4X
Enclosure Width
36"
Enclosure Height
48"
Component
Disconnect Enclosure
Enclosure Door Type
Solid
Enclosure Mount Type
Wall Mount
Enclosure Number of Doors
1 Door
Cutout Type
Preferred Cutout
Manufacturer
Hoffman
Features
Hinges are fiberglass reinforced polyester
Seamless foam-in-place gasket assures water-tight and dust-tight seal
Fiberglass material is easily drilled, filed or sawed
Doors are secured with Type 304 stainless steel slotted quarter-turn latches
Seams are sealed, no holes or knockouts
Fiberglass-reinforced material has excellent temperature and chemical resistance qualities and exhibits outstanding physical properties
Data pocket is high-impact thermoplastic
Internal grounding provisions for quarter-turn latches
Holes provided in body for mounting disconnect operating handle and operating mechanism, disconnect operating handle not included
Copper flashed steel collar studs for mounting optional panels and terminal block kits
Downloads
Hoffman A48HS3612GQRLP 2D DXF CAD.zipHoffman A48HS3612GQRLP 3D STEP CAD.zipHoffman A48HS3612GQRLP CAD Drawing.zipHoffman A48HS3612GQRLP Declaration of Compliance.pdfHoffman A48HS3612GQRLP Dimension Drawing.gifHoffman A48HS3612GQRLP Disconnect Devices Installation Instructions.pdfHoffman A48HS3612GQRLP EU Certification.pdfHoffman A48HS3612GQRLP Instruction Manual.pdfHoffman A48HS3612GQRLP Latch Grounding Bars Installation Instructions.pdfHoffman A48HS3612GQRLP Spec Sheet.pdfHoffman A48HS3612GQRLP UL Certification.pdf
