Code: 16088
nVent Hoffman CP424518B CONCEPT HMI Steel Enclosure
nVent Hoffman CP424518B HMI Enclosure Steel with Blue Extrusions 16.73 x 17.72 x 7.09 inch (HxWxD) CONCEPT Type 4 Steel HMI Enclosure with Hinged rear corner-formed door has a single-point latch. (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next Day (DOES NOT INCLUDE BACK PANEL)$1541.89
Sale Price
$1284.91
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
nVent Hoffman CP424518B HMI Enclosure Steel with Blue Extrusions 16.73 x 17.72 x 7.09 inch (HxWxD) This nVent Hoffman CONCEPT steel enclosure has an assortment of possible modifications, making it ideal for many different projects. With a removable front plate, the ability for cutouts anywhere on the enclosure, and a pendant or pedestal mounting system, this sturdy enclosure is sure to fit in any location. There are integral handle extrusions along the length of the profile with a comfort grip. With an aluminum front plate, the standard color is blue and four additional accent colors, blue, purple, red or turquoise, for the integral handle extrusions the end caps, this nVent Hoffman CONCEPT enclosure will look great in a variety of locations.
Specifications
HMI Environment Rating
Outdoor-Indoor
HMI Door Type
Solid
HMI Composition
Steel
HMI Interior Color
Gray
HMI Width
18.0"
HMI Depth
8.0"
HMI Height
17.0"
HMI Mount Type
Pendant/Pedestal Mount
Line
CONCEPT
Component
HMI Enclosure
HMI NEMA Rating
NEMA Type 4
HMI NEMA Rating
NEMA Type 12
HMI Number of Doors
1 Door
Manufacturer
Hoffman
Features
Aluminum removable front plate is .125-in aluminum
Integral aluminum handle extrusions have a comfort grip that extends the length of the profile, available in black or blue
Hinged rear corner-formed door has a single-point latch, seamless foam-in-place gasket and panel studs
Grounding stud on body, bonding provision on door
Pedestal mounting when enclosure is inverted
Pre-drilled hole in top for pendant arm mounting
Simple easy-to-remove and install hinge pins with built-in captive clip
High-torque threadless studs and fasteners on door for mounting optional door panel
Downloads
Hoffman CP424518B 2D DXF CAD.zipHoffman CP424518B 3D STEP CAD.zipHoffman CP424518B CAD Drawing.zipHoffman CP424518B Declaration of Compliance.pdfHoffman CP424518B EU Certification.pdfHoffman CP424518B Instruction Manual.pdfHoffman CP424518B Spec Sheet.pdfHoffman CP424518B UL Certification.pdfHoffman CP424518B User Manual.pdf
