Code: 153150
Phoenix Contact 3073416 Panel feed-through terminal block UWV 10/S
Normally In Stock
Phoenix Contact 3073416 UWV 10/S ,Copper Alloy,PA,I Panel feed-through terminal block
Condition: New
Usually ships Same Day or Next Day $14.34
Sale Price
$11.95
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 3073416 A panel feed-through terminal block is available with a screw connection method using a tension sleeve, featuring one position and accommodating load currents up to 57 A. The cross-sectional area ranges from 0.5 mm² to 16 mm², while the width of the connector measures 10.1 mm and is characterized by a gray color with a specific connection orientation of -90° relative to the plug-in direction.
Specifications
Terminal Block Amperage
57 Amp
Terminal Block Amperage
76 Amp
Terminal Block Voltage Rating
320 Volt
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Panel Feed-Through Terminal Block
Terminal Block Voltage Rating
4 Kv
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Tool-free snap-in principle enables easy mounting on the device panel
Automatic panel thickness compensation enables universal use
