Phoenix Contact 1080227 Power connector SACC-M12FSS-2PEPL-CM SH
Normally In Stock
Code: 149378
Phoenix Contact 1080227 - Power connector - 3 Positions - 16 AWG - 60 V - IP65 - Push-Lock Connection - M23
Condition: New
Usually ships Same Day or Next Day$76.32
Sale Price
$63.60
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1080227 A power connector featuring a 3-position configuration with shielding, it has a straight M12 socket and is identified by the code "S". The connection type utilizes a push-lock mechanism secured by a spring, while the knurl material used is brass that has been nickel-plated. The external diameter of the cable ranges from 6 mm to 11 mm.
Specifications
Connector protection
IP65
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
3
Sub Component
Power Connector-Cable Side
Connector Voltage
60 Volt
Features
Time-saving Push-Lock connection: Tool-free connection and disconnection of conductors by opening the contact levers
Intuitive connection: Easy assignment of individual litz wires with color-coded and numerical identification of the contact levers
Integrated Push-in Technology: Wire rigid and pretreated conductors easily by means of simple, direct insertion
Shock- and vibration-resistant connection: Proven spring-cage technology guarantees secure and reliable contacting
Increased protection against electric shock: PE connection to all metal components
Safely shielded: Reliable 360° shield connection even under extreme mechanical strain
Protected seal in the M12 socket

Code: 149378
Phoenix Contact 1080227 Power connector SACC-M12FSS-2PEPL-CM SH
$76.32
Sale Price
$63.60
