Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Dwyer RMC-144-SSV Water and Liquid Flow Meter
Normally In Stock
Code: 14819
Dwyer RMC-144-SSV Water and Liquid Flow Meter (Rate-Master) 10" Scale with Stainless Steel Valve,range .8-7 GPM water (48-420 GPH)(3636-31822 CCM). Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 2%,Process Connection 1/2" Weight 39 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are Stainless Steel except for optional brass valve,Float is Stainless steel,black glass,aluminum,K monel,tungsten carbide.
Condition: New
Usually ships Same Day or Next Day$282.20
Sale Price
$235.17
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer RMC-144-SSV Water and Liquid Flow Meter (Rate-Master) 10" Scale with Stainless Steel Valve,range .8-7 GPM water (48-420 GPH)(3636-31822 CCM). Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 2%,Process Connection 1/2" Weight 39 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are Stainless Steel except for optional brass valve,Float is Stainless steel,black glass,aluminum,K monel,tungsten carbide.
Specifications
Component
Water And Liquid Flow Meter
(Instrument-Sensor) Type
Variable Area
(Instrument-Sensor) Type of Operator
Stainless Steel Valve
(Instrument-Sensor) Temperature Range
103 F
(Instrument-Sensor) Size
0.5"
(Instrument-Sensor) Output Signal Type
10" Scale
(Instrument-Sensor) Span
31822 CCM
(Instrument-Sensor) Span
3636 CCM -
(Instrument-Sensor) Span
.8 GPM - 7 GPM
(Instrument-Sensor) Span
48 GPH - 420 GPH
(Instrument-Sensor) Measurement Accuracy
2.0%
Manufacturer
Dwyer Instruments
Features
Eliminate the need for troublesome conversions with direct reading scales
Reduce installation damage and cost due to stainless steel backbone that absorbs piping torque
Long operation life with durable, shatter-proof polycarbonate body
High repeatability enabled by precision injection molding around a precision tapered pin
Increased reading accuracy with special integral flow guides that stabilize float movement
Save time with instantaneous flow reading with the presence of scale graduations on both side of the indicating tube
