Phoenix Contact 1705668 The printed circuit board terminal has a nominal current capacity of 41 A and is rated for 320 V, with a cross-sectional area of 4mm². It features three potentials, arranged linearly across one row of three positions. The product range is KDSP 4, with a pitch of 7.5mm, employing screw connections with tension sleeves featuring L-slotted screw heads. Wave soldering is used for mounting, and the conductor/PCB connection direction is at 0° degrees, while the pin layout follows a linear configuration. Each potential has two solder pins spaced 5mm apart from each other, and the entire terminal comes packaged in cardboard.
