Dwyer RMA-11 Air and Gas Flow Meter
Normally In Stock
Code: 14723
Dwyer RMA-11 Variable Area Flowmeter (Rate-Master) 2" Scale with No Valve,range 30-240 cc/min air (.03-.24 LPM),(.063-.508 SCFH). For compatible gases and liquids. Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 4%,Process Connection 1/8" Weight 4 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are No except for optional No valve,Float is No,black glass,aluminum,K monel,tungsten carbide.
Condition: New
Usually ships Same Day or Next Day$69.50
Sale Price
$57.92
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer RMA-11 Variable Area Flowmeter (Rate-Master) 2" Scale with No Valve,range 30-240 cc/min air (.03-.24 LPM),(.063-.508 SCFH). For compatible gases and liquids. Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 4%,Process Connection 1/8" Weight 4 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are No except for optional No valve,Float is No,black glass,aluminum,K monel,tungsten carbide.
Specifications
Component
Air And Gas Flow Meter
(Instrument-Sensor) Size
0.125"
(Instrument-Sensor) Type
Variable Area
(Instrument-Sensor) Output Signal Type
2" Scale
(Instrument-Sensor) Temperature Range
103 F
(Instrument-Sensor) Span
.063 SCFH - .508 SCFH
(Instrument-Sensor) Span
.03 LPM - 240 CCM
(Instrument-Sensor) Span
30 CCM - .24 LPM
(Instrument-Sensor) Type of Operator
No Valve
(Instrument-Sensor) Measurement Accuracy
4.0%
Manufacturer
Dwyer Instruments
Features
Eliminate the need for troublesome conversions with direct reading scales
Reduce installation damage and cost due to stainless steel backbone that absorbs piping torque
Long operation life with durable, shatter-proof polycarbonate body
High repeatability enabled by precision injection molding around a precision tapered pin
Increased reading accuracy with special integral flow guides that stabilize float movement
Save time with instantaneous flow reading with the presence of scale graduations on both side of the indicating tube
