Phoenix Contact 1888276 PCB terminal block FFKDSA1/V-2,54- 9
Normally In Stock
Code: 146635
Phoenix Contact 1888276 FFKDSA1/V-2,54- 9 ,Copper Alloy,PA,I PCB terminal block *NON-CANCELLABLE, NON-RETURNABLE*
Condition: New
Usually ships Same Day or Next Day *NON-CANCELLABLE, NON-RETURNABLE*
$12.04
Sale Price
$10.03
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1888276 A printed circuit board terminal has a nominal current capacity of 6 A and is rated for a voltage of 160 V at a temperature class III/2. It features a cross-sectional area of 0.5 mm², allowing it to accommodate 9 potentials. The terminal's layout includes 1 row with 9 positions per row, with the product range specified as FFKDS(A) 0,5/..-V. The pitch between pins is 2.54 mm and uses a push-in spring connection method for wave soldering mounting.
Specifications
Connector Amperage
6 Amp
Connector Voltage
2.5 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Sub Component
PCB Terminal Block
Number of Connections
9
Number of Positions
9
Component
PCB
Connector Voltage
63 Volt
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Operation and conductor connection from one direction enable integration into front of device
Two solder pins reduce the mechanical strain on the soldering spots
The latching on the side enables various numbers of positions to be combined
Vertical connection enables multi-row arrangement on the PCB
