Phoenix Contact 1947175 The PCB connector features a nominal cross-section of 2.5mm², is colored green, and has a maximum current rating of 12A with an operating voltage of up to 320V for safety. The contact surface material is tin and utilizes a socket connection type, providing 14 individual potentials. With a pitch of 5mm, the connector allows for push-in spring connections, where the conductor meets the PCB in a 0-degree angle. A locking clip secures the connection, and the plug-in system employs a Combicon MSTB 2.5 design, featuring snap-in locking and latching flanges for secure mounting on a cardboard-based packaging.
