Phoenix Contact 1966127 PCB connector FMC 1,5/ 5-STF-3,5
Normally In Stock
Code: 145888
Phoenix Contact 1966127 FMC 1,5/ 5-STF-3,5 ,Copper Alloy,PA,I,PBT Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $6.07
Sale Price
$5.06
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1966127 The connector features a nominal cross-section area of 1.5mm², is green in color and has a rated current of 8A with a maximum voltage of 160V. It has a socket contact connection type, five potential contacts, a single row design, and comes in the FMC 1.5/..-STF product range with a pitch of 3.5mm. Connection is made by push-in spring method, with conductor to PCB alignment at 0° angle, utilizing a COMBICON FMC 1.5-MCDN 1.5 plug-in system and secured via screw locking mechanism, mounted using a screw flange in a cardboard packaging.
Specifications
Connector Amperage
8 Amp
Connector Material
PBT
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Sub Component
PCB Terminal Block
Number of Connections
5
Number of Positions
5
Component
PCB
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Operation and conductor connection from one direction enable integration into front of device
Screwable flange for superior mechanical stability
