Phoenix Contact 1844219 PCB connector IFMC 1,5/ 2-ST-3,5-RF
Normally In Stock
Code: 145249
Phoenix Contact 1844219 IFMC 1,5/ 2-ST-3,5-RF ,Copper Alloy,PA,I,PBT Printed-circuit board connector *NON-CANCELLABLE, NON-RETURNABLE*
Condition: New
Usually ships Same Day or Next Day *NON-CANCELLABLE, NON-RETURNABLE*
$6.54
Sale Price
$5.45
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1844219 The PCB connector has a nominal cross-sectional area of 1.5 mm2 and is colored green, with a rated current of 8A and a maximum voltage of 160V. It features a Sn contact surface, a pin connection type with two potentials, and is packaged with snap-in locking, packed in cardboard.
Specifications
Connector Amperage
8 Amp
Connector Material
PBT
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Connections
2
Number of Positions
2
Component
PCB
Sub Component
PCB Plug
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Inverted connector with pin contacts for touch-proof device outputs or free-hanging cable/cable connections
Intuitive locking mechanism prevents accidental disconnection
