Phoenix Contact 1897403 PCB connector QC 0,5/ 3-ST-3,81
Normally In Stock
Code: 144083
Phoenix Contact 1897403 QC 0,5/ 3-ST-3,81 ,Copper Alloy,PA,I Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $7.92
Sale Price
$6.60
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1897403 The PCB connector has a nominal cross-sectional area of 0.5 mm², measured as green in color, with a maximum current rating of 6 A and a rated voltage of 200 V (III/2). It features a copper-plated zinc contact surface, employs a socket connection type, and offers three potentials, arranged in one row with three positions, connections, and connectors. This connector is part of the QC 0.5/...-ST product range, has a pitch of 3.81 mm, utilizes a displacement connection method, and allows for plug-in compatibility via the COMBICON MC 1.5 system, without any locking mechanism or mounting requirements. The connector is packaged in cardboard, ready for use.
Specifications
Connector Amperage
6 Amp
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Connections
3
Number of Positions
3
Component
PCB
Sub Component
PCB Plug
Connector Voltage
400 Volt
Connector Voltage
200 Volt
Features
Connection without conductor pretreatment for huge time savings
Quick and convenient testing using integrated test option
