Meltric 37-28109 Direct Current DSDC2 Inlet 130 VDC 200A Blue Metal
Normally In Stock
Code: 131513
Meltric 37-28109 Direct Current DSDC2 Inlet 130 VDC 200A Blue Metal 2P+G
Condition: New
Usually Ships Same Day or Next DayMUST ORDER A MINIMUM OF $110 FROM MELTRIC FOR PRODUCT TO SHIP
$1215.86
Sale Price
$1013.22
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Meltric 37-28109 Direct Current DSDC2 Inlet 130 VDC 200A Size 6 2P+G Blue Metal Screw Terminal UL 498,UL 1682
Specifications
Receptacle Composition
Metal
Receptacle Color
Blue
Receptacle Contact Configuration
2P+G
Receptacle Amperage
200 Amp
Receptacle NEMA Type
Type 3R
Receptacle Wiring Connection Type
Screw Terminal
Receptacle UL Listing
UL 498
Receptacle UL Listing
UL 1682
Receptacle Min Wire Size
4 AWG
Receptacle Voltage
130 VDC
Receptacle Size
Size 6
Receptacle Max Wire Size
4/0 AWG
Manufacturer
Meltric
Meltric Series
DSDC2
Component
Inlet
Features
Release Pawl Provided with a lockout hole to prevent disconnection under load
Dead-front Ensures safety by preventing user access to live parts.
Dead-front Ensures safety by preventing user access to live parts.
Lockout-Tagout Provisions Allows plug to be easily locked out and tagged out. Optional Padlock Pawl allows lockout /tagout of the receptacle
Silver-Nickel Contact Material Solid silver-nickel contact surfaces provide superior conductivity, durability and corrosion resistance.
Lid Provides additional protection from harsh environments.
Spring-Loaded Butt-Style Contacts Ensures optimal contact force and superior electrical performance over thousands of operations.
