ABB TED136125 MCCB 600 VAC, 125 Amp, Three Pole
Normally In Stock
ABB TED136125 Molded Case Circuit Breaker - 600 VAC - 125 Amp - Three Pole
Condition: New
Usually ships Same Day or Next Day$2538.25
Sale Price
$2115.21
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
ABB TED136125 - The E150 product line consists of Thermal Magnetic Circuit Breakers, Magnetic Circuit Breakers, and Molded-Case Switches rated up to 150 Amps and 600 Volts AC. Catalog numbers include the complete breaker or switch. The WL catalog number suffix indicates that the devices come with Cu/Al line and load lugs. All TEB, TED, THED breakers suitable for reverse feed. 60/75 C rating through 100 amperes, 75 C rating above 100 amperes. 3 POLE 600VAC 125A BREAKER
Specifications
Amperage (Molded Case Breaker)
125 Amp
Poles (Molded Case Breaker)
Three Pole
Maximum Voltage (Molded Case Breaker)
600 VAC
Manufacturer
ABB
Component
Molded Case Circuit Breaker
Features
Reliable Thermal-Magnetic Trip Units: The TED breakers utilize thermal-magnetic trip units to provide dependable protection against overloads and short circuits. This type of trip unit combines a bimetallic strip (thermal element) for overload protection and an electromagnet (magnetic element) for short-circuit protection.
Trip-Free Mechanism: The trip-free mechanism ensures that the breaker trips and opens the circuit under fault conditions, even if the operating handle is held in the "on" position. This prevents the contacts from being "teased" into position, which could cause arcing and damage.
Quick-Make, Quick-Break Operation: The quick-make, quick-break mechanism minimizes arcing during breaker operation, contributing to longer contact life.
Common Trip Bar: In multi-pole breakers, a common trip bar ensures that all conductors are disconnected simultaneously when an overload or short circuit occurs on any one conductor or when an accessory trip device operates.
High Mechanical and Dielectric Strength: The molded case of the TED breakers is constructed from engineered plastic with high mechanical and dielectric strength, providing robust construction and electrical insulation.
Silver Alloy Contacts: The breakers feature silver alloy contacts that offer good conductivity and minimize pitting and burning, leading to longer contact life.
Arc Chutes: Heat-absorbing, insulating materials and metal grid plates within the arc chutes effectively extinguish arcs that can form when the breaker interrupts a fault.
UL Listed Lugs: The breakers come with UL-listed lugs designed to accommodate both copper and aluminum cables at the full frame rating. They are easily accessible and allow for straightforward, straight-in wiring.
Reverse Feed Suitability: All TEB, TED, and THED series breakers are suitable for reverse feed applications, increasing their versatility.
