ABB THQC2150 Mini CB - 50 Amp, 2P
Normally In Stock
Code: 121650
ABB THQC2150 - Miniature Circuit Breaker - 120/240 VAC - 50 Amp - Two Pole
Condition: New
Usually ships Same Day or Next Day$86.12
Sale Price
$71.77
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
ABB THQC2150 Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QC breakers are lug-lug versions of the Q Line and are available for 35mm DIN rail mounting. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions and can be ordered with auxiliary contact and shunt trip accessories.
Specifications
Breaker Mechanism Type
Toggle
Breaker Amperage Rating
50 Amp
Breaker Number of Poles
Two Pole
Breaker Voltage Rating
120 VAC
Breaker Voltage Rating
240 VAC
Component
Miniature Circuit Breaker
Breaker Function
LI
Manufacturer
ABB
Line
Q-Line
Features
Q-Line Frame: They belong to the Q-Line family, a series of compact, thermal-magnetic circuit breakers.
Lug-to-Lug Connection: Unlike the plug-in THQL, THQC breakers are designed with lug connections for both line and load terminals.
DIN Rail Mounting: They are available for mounting on a 35mm DIN rail.
Thermal-Magnetic Trip: They provide protection against overloads and short circuits using a fixed thermal-magnetic (LI - Long Time and Instantaneous) trip unit.
Interrupting Rating: THQC breakers typically have a 10 kAIC (kiloampere interrupting capacity) rating at 120/240 VAC.
Safety Features: They feature quick-make/quick-break mechanisms, common trip bars, and an easy-to-spot trip indication (handles trip to the center position) to enhance safety and reliability.
Durability: The cases and covers are made of heat-resistant thermoset for stability and structural rigidity, and they use tin-plated copper stabs for corrosion resistance and reliable connections.
Wire Compatibility: They are designed to accept a range of copper and aluminum wire sizes.
Optional Features: They can be ordered with auxiliary contacts and shunt trip accessories
