Phoenix Contact 2839648 Type 3 surge protection plug PT 2+1-S-48DC-ST
Normally In Stock
Code: 1164
PT 2+1-S-48DC-ST Phoenix Contact PT 2+1-S-48DC-ST Protective plug PT with device surge protection for power supply units, visual fault warning. Nominal voltage: 48 V AC
Condition: New
Usually ships Same Day or Next Day$209.18
Sale Price
$174.32
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2839648 A protective plug designed to provide surge protection for power supply units features a visual error display, indicating any potential issues, and operates at a nominal voltage of 48 V AC.
Specifications
Surge Protector Mount
Din Rail Mount
Fault Warning
Optical
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Direction of Action
Line-Line
Direction of Action
Line-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Push-In Connection
Surge Protector Line Voltage
48 Volt
Surge Protector Type
Surge Protection For Measurement And Control Technology
Maximum Continous Voltage
36 Volt
Nominal Discharge Current
0.5 Ka
Component
Surge Protection Plug
Features
The signal is not influenced during maintenance work, thanks to the impedance-neutral insertion and removal of protective plugs
Maximum ease of maintenance, thanks to the 2-piece design
Easy selection for all possible demands in MCR applications with a complete product portfolio
Easy testing and documentation with CHECKMASTER 2 with pluggable protective modules
Downloads
Phoenix 2839648 CAD data International.dxfPhoenix 2839648 CAD data International.pdfPhoenix 2839648 CAD data International.stpPhoenix 2839648 CAD Drawing.zipPhoenix 2839648 Flyer English.pdfPhoenix 2839648 Manufacturers declaration English.pdfPhoenix 2839648 Manufacturers declaration International.pdfPhoenix 2839648 Package Slip International.pdfPhoenix 2839648 Product Information English.pdfPhoenix 2839648 Software International.zipPhoenix 2839648 Spec Sheet.pdfPhoenix 2839648 Surge Protection English.pdfPhoenix 2839648 Tender Text English.zipPhoenix 2839648 User Manual.pdf
