Schneider Electric METSEION7400 PowerLogic ION7400 Panel mount meter - display - optical port and 2 pulse
Normally In Stock
Code: 114487
Schneider METSEION7400 Colour TFT LCD Flush-mounted 3 digital 30 V AC, 3 digital 60 V DC Power meter 320 x 240 pixels QVGA Voltage, Current, Frequency, Power, Energy consumption, Harmonic distortion ION7400 50 Hz, 60 Hz 1 pulse Ethernet, Screw terminal block RS485, Optical probe
Condition: New
CALL FOR LEAD TIME$12929.11
Sale Price
$10774.26
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
PowerLogic ION7400 Panel mount meter - display - optical port and 2 pulse
Specifications
Monitoring Switching Output
1 Pulse
Monitoring Interface
320 X 240 Pixels QVGA
Manufacturer
Schneider Electric
Monitoring Type
Voltage
Monitoring Type
Current
Monitoring Type
Frequency
Monitoring Type
Power
Monitoring Type
Energy Consumption
Monitoring Type
Harmonic Distortion
Monitoring Connection Method
Ethernet
Monitoring Connection Method
RS485
Monitoring Connection Method
Optical Probe Fiber Optic
Monitoring Connection Method
Mini B USB
Component
Power Meter
Features
PowerLogic ION7400 utility feeder power meters combine capabilities not typically available in compact meters
They offers a hight flexibility and usability, along with accurate 3-phase energy and power measurements with data logging
Use Power Monitoring Expert software for data analysis or share operation data with SCADA systems through multiple communication channels and protocols
Certified by third party labs for energy accuracy (IEC 62052-11, IEC 62052-22, IEC 62052-24) and power quality (IEC 62586-2, IEC 61000-4-30 Class S)
Cybersecurity features include secure protocols (HTTPS, SFTP), security event logging, Syslog protocol
Ability to enable/disable communication ports, and 16 user configurable accounts
With 512 MB of memory to support 50 data logs, 50+ user-definable alarms, waveform captures, 1/2 cycle RMS logging, custom web pages, min/max logs, energy trends, and Time of Use
The ability to timestamp events to +/-1 ms utilizing time synchronization method that include PTP (IEEE1588), NTP, IRIG-B, GPS ASCII (RS485) and network time set function
3 digital inputs and one digital output
I/O option modules include 2 relays and 6 digital inputs or 2 analog outputs and 4 analog inputs
Wide control power range of 90-415 VAC / 110-415 VDC
Operating environment of -25 to +70C
Humidity rating of 5% to 95%
Altitude up to 3000 m
Panel mounting (1/4 DIN) with integrated display.
