Phoenix Contact 2817987 Type 2 surge arrester F-MS 12
Normally In Stock
Code: 1081
F-MS 12 Phoenix Contact F-MS 12 Surge arrester type 2, consisting of base element and protective plug with N-PE total current spark gap for mounting on NS 35/7.5, housing width: 17.5 mm (1 Div.)
Condition: New
Usually ships Same Day or Next Day$169.01
Sale Price
$140.84
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2817987 A surge arrester type 2 is designed with a base element and protective plug that features an N-PE total current spark gap, suitable for installation on the NS 35/7.5 mounting bracket with a housing width of 17.5mm ( equivalent to one division).
Specifications
Surge Protector Mount
Din Rail Mount
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Arrester Class according to IEC
D1
Direction of Action
Line-Line
Direction of Action
Line-Signal Ground-Shield
Direction of Action
Optional Signal Ground-Shield-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Push-In Connection
Surge Protector Type
Surge Protection For Information Technology
Maximum Continous Voltage
15 Volt
Nominal Discharge Current
5 Ka
Surge Protector Line Voltage
240-415 Volt
Component
Surge Arrester
Features
Wide range of applications due to various nominal voltages
Rapid installation with bridges, thanks to industry-standard overall width of 1 HP
Easy testing and insulation measurement, thanks to pluggable protection modules
Quality proven millions of times over in the widest range of applications
High degree of modularity provides individual solutions for every application
Downloads
Phoenix 2817987 CAD data International.dxfPhoenix 2817987 CAD data International.pdfPhoenix 2817987 CAD data International.stpPhoenix 2817987 CAD Drawing.zipPhoenix 2817987 Certification English.jpgPhoenix 2817987 EPLAN Macro International.zipPhoenix 2817987 Flyer English.pdfPhoenix 2817987 Manufacturers declaration English.pdfPhoenix 2817987 Manufacturers declaration International.pdfPhoenix 2817987 Package Slip International.pdfPhoenix 2817987 Product Information English.pdfPhoenix 2817987 Software International.zipPhoenix 2817987 Spec Sheet.pdfPhoenix 2817987 Surge Protection English.pdfPhoenix 2817987 Tender Text English.zipPhoenix 2817987 User Manual.pdf
