Phoenix Contact 2817990 Type 2 surge protection plug F-MS 12 ST
Normally In Stock
Code: 1091
F-MS 12 ST Phoenix Contact F-MS 12 ST Surge protection plug type 2, with N-PE total current spark gap for base element.
Condition: New
Usually ships Same Day or Next Day$149.26
Sale Price
$124.38
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2817990 A surge protection plug Type 2 features a base element equipped with an N-PE (Non-conductive Part of Earth) total current spark gap, designed to provide protection against electrical surges.
Specifications
Surge Protector Mount
Din Rail Mount
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Arrester Class according to IEC
D1
Direction of Action
Line-Line
Direction of Action
Line-Signal Ground-Shield
Direction of Action
Optional Signal Ground-Shield-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Push-In Connection
Surge Protector Type
Surge Protection For Measurement And Control Technology
Maximum Continous Voltage
30 Volt
Nominal Discharge Current
5 Ka
Surge Protector Line Voltage
240-415 Volt
Component
Surge Protection Plug
Features
Easy and safe installation with forward-thinking handling and safety features
Reliable system protection with maximum performance and endurance
Can be used in a wide range of applications due to the optimized design and broad portfolio
Simple planning due to comprehensive digital data and selectors
Downloads
Phoenix 2817990 CAD data International.dxfPhoenix 2817990 CAD data International.pdfPhoenix 2817990 CAD data International.stpPhoenix 2817990 CAD data International.wrlPhoenix 2817990 CAD Drawing.zipPhoenix 2817990 Flyer English.pdfPhoenix 2817990 Manufacturers declaration English.pdfPhoenix 2817990 Manufacturers declaration International.pdfPhoenix 2817990 Package Slip International.pdfPhoenix 2817990 Software International.zipPhoenix 2817990 Spec Sheet.pdfPhoenix 2817990 Surge Protection English.pdfPhoenix 2817990 Tender Text English.zipPhoenix 2817990 User Manual.pdf
