pH, ORP, conductivity & flow parameters available

Highly visible large LCD display

Flexible and easy calibration, including multi-point conductivity calibration for acids and bases

4-20mA process output with range scaling and PID Control

Additional Features 1pH, ORP, Conductivity, Flow. Wall or Panel Mounting

ApplicationsBoilers, Chemicals, Cooling Towers, Food and Beverage, Fume scrubbers, Industrial and Manufacturing, Mining, Pulp & Paper, Waste Management

ApprovalsETL (US and Canada) and CE pending

Calibration NotepH Calibration Modes: Automatic or Manual 2 or 3 points ORP Calibration Modes: Manual 1 point Conductivity Calibration Modes: Up to 16 points Flow Calibration Modes: K-factor input

Conductivity Measurement0.055 to 500,000 µS/cm

Electrical Output4 to 20 mA

Enclosure RatingsNEMA Type 4X

Flow Indication Note0 to 999 in any units

Front Cover Height5.5 in

Front Cover Width5.5 in

Height5.4 in

Input Range NotepH Sensor Input: -600 to +600 mV ORP Sensor Input: -999 to +999 mV Conductivity Sensor Input: 0 to 9999 Ω Flow Sensor Input: 0 to 2000 Hz

Length5 in

Load Resistance800 Ω

Measurement TypeConductivity, pH, ORP, Flow

MountingWall mount, panel mount with kit provided. DIN rail and pipe mount with optional kit

Operating Temperature, Max70 °C

Operating Temperature, Min-20 °C

ORP Measurement Range-1000 to +1000 mV

Output DetailOne 4-20 mA output Scalable 4-20mA with PID (Process) Optically isolated.

PH Measurement Range0 to 14.00 pH

Power Consumption20 mA @ 24 Vdc

Relative Humidity0 to 90% Relative Humidity, non-condensing

Sensor NotePH Sensor 6-Wire Differential or Combination ORP Sensor 6-Wire Differential or Combination Conductivity Sensor 4-Wire contacting : Any cell constant between 0.01 and 100 Flow Sensor Pulse output: Paddle-wheel, PH Temerature elements Magmete 100, 1000 Ω, RTD 300, 3000 Ω NTC ORP Temerature Elements 100, 1000 Ω, RTD 300, 3000 Ω NTC Conductivity Temperature Elements 100, 1000 Ω, RTD 300, 3000 Ω NTC

Temperature CompensationpH : Automatic

ORP : Display temperature

Conductivity: Automatic or Manual -20 to 120 °C

Flow: Display Flow Totalizer

Temperature RangepH range: -20 to 120 °C

ORP range: -20 to 120 °C

Conductivity range: -20 to 120 °C

Weight2 lb

Width5.4 in
