Easy to Read 25 mm (1') Backlit LCD Display

High 0.08% Accuracy Typical

Hi and Lo Alarms Standard

MIN/MAX/AVG Reading

Accuracy Class< 0.1%

Accuracy Detail± 0.08% Best Straight Line Typ. (Linearity, Hysteresis and Repeatability combined)

Battery life9 mo

Battery Size and Type3.6V Li-ion

Burst Pressure6x Full Scale

Cable Length2.7 m

Calibration Note5-Pt NIST traceable Calibration with zero and span values, Calibrated in horizontal direction (Compound Gage models calibrated in positive direction only)

ComplianceCE

Connection LocationLower

Data InterfaceUSB

Data Interface NoteUSB connection for set-up, cable included

Display Segment Height25 mm

Display Type4 Digit LCD

Display Type Note4-digit LCD with user selectable backlighting, (9999 count) 25 mm (1') character height.

Electrical Output4 to 20 mA

Electrical Output NoteUser selectable 0 to 5 Vdc, 0 to 10 Vdc of 4 to 20 mA (external 24 Vdc power required)

Enclosure Material316 Stainless Steel

Enclosure RatingsIP65, NEMA Type 4X, Weatherproof

Fill FluidNEOBEE M5 food grade

Isolation between Case and Output Terminations, Min100MΩ @ 50 Vdc

Materials, Wetted316 Stainless Steel

Number of Batteries1

Number of Digits4

Operating Temperature, Max66 °C

Operating Temperature, Min-18 °C

Output SignalCurrent, Voltage

Pressure Accuracy± 0.08 %

Pressure Cycles250000

Process Connection Note11 ⁄2 and 2" Tri-GripTM Fitting (compatible with Tri-Clamp®): 600 psi using suitable clamp (600 psi on 11 ⁄2" Tri-Clamp® only)

Process Connection TypeTri-Clamp

Sample/Display Rate0.25 to 10 sec

Sample Display Rate NoteUser selectable from 0.25 to 10 sec. (preset to 1/sec)

Sensor Dimension Note72 to 89 mm L (2.8 to 3.5") below display

Settable ParametersBacklight, Min, Max, Zero, Clear

Software SettingsSoftware Settings (via USB) Update Rate: 4 options, 10, 5, 2, 1 times per second Units: psi, inHg, inH2O, bar, mbar, hPa units

must be specified at time of order Lock: Allows the lock-out of front panel functions Alarms: User selectable “High” and “Low” alarm limits (open collector) Backlight: On/off, 10 sec, 30 sec, 1 min, 5 min Wireless Transmitter (Optional): Channel number, transmission rate, alarms, sensor offset, chart recording, data logging Calibrate: Zero and Span Overrange Indication: “_ _ _ _”

Span Setting± 0.5% FS typical ± 1% maximum (For ranges ≤2.5 psi ± 1% Typical ± 2% maximum)

Storage Temperature, Max82 °C

Storage Temperature, Min-40 °C

Supply Power TypeBattery

Thermal EffectsThermal Effect (Over Compensated Range): Zero and Span shift over Compensated Range

Ranges: ≤2.5 psi: Zero: 1.00% Span: 0.70%

5 psi: Zero: 0.80% Span: 0.50%

> 5 psi: Zero: 0.50% Span: 0.50%

26B & 26HB Barometric Range: Zero: 0.90% Span: 0.50%

Weight900 g

Weight Note900 g (2 lb) Typical depending upon configuration

Wireless Option SpecificationsTransmit Sample Rate: User programmable from 1 sample/2 min to 1 sample/2 sec Radio Frequency (RF) Transceiver Carrier: ISM 2.4 GHz RF Output: 10 dBm (10 mW) Range of RF Link: Outdoors (Line of Sight): Up to 120 m (400') Indoors/Urban: Up to 40 m (130') Included Software: Requires Windows® 7 (32 bit)

XP, Vista Internal Battery: Two 3.6V lithium 8.4 Ah capacity (C-cell) included Data Transmission to Host: Pressure reading, ambient temperature reading, RF transmit strength and battery level

Zero/Balance Error± 0.5% FS typical ± 1% maximum (For ranges ≤2.5 psi ± 1% Typical ± 2% maximum)
