NEW RANGES! Sealed Gage, Compound Gage, Vacuum and, Barometric Ranges

5-Point NIST Traceable Calibration Included

High 0.08% Accuracy on most Ranges

Selectable 4 to 20 mA, 0 to 5V or 0 to 10V Analog Output

Accuracy Class< 0.1%

Accuracy DetailAccuracy (Combined Linearity, Hysteresis and Repeatability): ± 0.08% BSL (compound gauge calibrated in positive direction only)

Battery life9 mo

Battery Size and TypeAlkaline

Cable Length2.7 m

ComplianceCE

Connection LocationLower

Data InterfaceUSB

Data Interface NoteUSB connection for set-up, cable included

Display Segment Height25 mm

Display Type4 Digit LCD

Display Type Note4-digit LCD with user selectable backlighting, (9999 count) 25 mm (1') character height.

Electrical Output4 to 20 mA

Electrical Output NoteUser selectable 0 to 5 Vdc, 0 to 10 Vdc or 4 to 20 mA (external 24 Vdc power supply required for all analog output types) Set jumper to select current or voltage Software selection of 0 to 5 Vdc, 0 to 10 Vdc, or 4 to 20 m

Enclosure Material316 Stainless Steel

Enclosure RatingsIP65, NEMA Type 4X, Weatherproof

Isolation between Case and Output Terminations, Min100MΩ @ 50 Vdc

Materials, Wetted316 Stainless Steel

Number of Batteries2

Number of Digits4

Operating Temperature, Max66 °C

Operating Temperature, Min-18 °C

Output SignalCurrent, Voltage

Pressure Accuracy± 0.08 %

Process Connection Size1/4 in

Process Connection TypeNPT Male

Sample/Display Rate0.38 to 30 seconds

Sample Display Rate NoteUser selectable from 0.38 to 30 sec. (preset to 1/sec)

Sensor Dimension Note72 to 89 mm L (2.8 x 3.5") below display

Settable ParametersBacklight, Min, Max, Zero, Clear

Software SettingsSoftware Settings (via USB) Update Rate: 4 options, 10, 5, 2, 1 times per second Units: psi, inHg, inH2O, bar, mbar, hPa units

must be specified at time of order Lock: Allows the lock-out of front panel functions Alarms: User selectable “High” and “Low” alarm limits (open collector) Backlight: On/off, 10 sec, 30 sec, 1 min, 5 min Wireless Transmitter (Optional): Channel number, transmission rate, alarms, sensor offset, chart recording, data logging Calibrate: Zero and Span Overrange Indication: “_ _ _ _”

Storage Temperature, Max82 °C

Storage Temperature, Min-40 °C

Supply Power NoteBattery Note:Two 1.5 V alkaline (C cell) included

Supply Power TypeBattery

Thermal EffectsThermal Effects (Over Operating Range): Zero Balance: Ranges >5 psi: ± 0.3% span Ranges ≤5 psi: ± 0.5% span Span Setting: Ranges >5 psi: ± 0.3% span Ranges ≤5 psi: ± 0.5% span

Weight900 g

Weight Note900 g (2 lb) Typical depending upon configuration

Wireless Option SpecificationsTransmit Sample Rate: User programmable from 1 sample/2 min to 1 sample/2 sec Radio Frequency (RF) Transceiver Carrier: ISM 2.4 GHz RF Output: 10 dBm (10 mW) Range of RF Link: Outdoors (Line of Sight): Up to 120 m (400') Indoors/Urban: Up to 40 m (130') Included Software: Requires Windows® 7 (32 bit)

XP or Vista Data Transmission to Host: Pressure reading, ambient temperature reading, RF transmit strength and battery level
