Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 5435284 PCB connector BCP-381F-19 GY
Normally In Stock
Code: 723374
Phoenix Contact BCP-381F-19 GY - PCB connector, 19 Positions, 3.81 mm, 160 VAC, 8 Amp, Cu alloy - 5435284
Condition: New
Usually ships Same Day or Next Day$15.53
Sale Price
$12.94
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5435284 A PCB connector features a signal gray color with an electrical specification of nominal current 8 A and rated voltage up to 160 V, utilizing a Sn contact surface with socket connection type for 19 potential connections across one row, supported by screw connections held in place by tension sleeves on a BCP-F product range with a pitch of 3.81 mm, secured via L Slotted screws and featuring a BASICLINE 1,5 plug-in system, packaged in cardboard.
Specifications
Connector Color
Green
Connector Amperage
8 Amp
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
3.81 mm
