Phoenix Contact 5452547 A PCB connector with a nominal cross-section of 1.5 mm2 features black contacts and is rated for an 8 A current with a maximum voltage of 160 V. The contact surface is tin-plated, utilizing a socket connection style with 19 potential pins arranged in one row across 19 positions. The pitch of this connector is 3.81 mm, secured through a screw connection with a tension sleeve and L Slotted screw head. The connections are achieved by a plug-in system called BASICLINE 1,5, featuring a screw locking mechanism for secure mounting via a screw flange, packaged in cardboard.
