Phoenix Contact 5435093 The PCB connector features a nominal cross-sectional area of 1.5 mm² and has a signal gray color. It is rated for a maximum current of 8 A and can handle up to 160 V, with a contact surface made of Sn. The connection type is socket-style, accommodating 19 potentials, arranged in a single row of 19 positions, corresponding to 19 connections. This connector falls within the BCP product range and has a pitch of 3.81 mm. It employs a screw connection method with a tension sleeve, using an L-slotted screw head, and allows for conductor-to-PCB connections at a 0° angle. The plug-in system is BASICLINE 1,5, and it does not require locking or mounting, instead being packaged in cardboard.
