Phoenix Contact 5434900 PCB connector BCP-350F-19 GY
Normally In Stock
Code: 723368
Phoenix Contact BCP-350F-19 GY - PCB connector, 19 Positions, 3.5 mm, 160 VAC, 8 Amp, Cu alloy - 5434900
Condition: New
Usually ships Same Day or Next Day$16.18
Sale Price
$13.48
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5434900 The specified PCB connector features a nominal cross-section area of 1.5 mm² and is identified by its signal gray color. The connector is rated for a maximum current of 8 A and can handle a voltage of up to 160 V as per the IEC III/2 standard. It has a contact surface made of tin (Sn) and operates using a socket connection method with screw attachment via tension sleeve, employing an L Slotted screw head form. The connector is part of the BASICLINE 1,5 plug-in system, features 19 positions for connections, and includes a screw locking mechanism for secure mounting in either cardboard packaging or by attaching to a flange for fastening.
Specifications
Connector Amperage
8 Amp
Connector Color
Black
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
3.5 mm
