Phoenix Contact 5452528 A PCB connector has a nominal cross-section of 1.5mm2 and is colored black, with a maximum current rating of 8A and a voltage rating of 160V for III/2 conditions. The contact surface is made of tin, using a socket connection type with 19 potentials, arranged in a single row of 19 positions, also featuring 19 connections. This connector falls within the BCP-F product range and features a pitch of 3.5mm. Connection is achieved via screw attachment with a tension sleeve, and includes an L-slotted screw head. Conductor to PCB connection occurs at a 0-degree angle, utilizing a BASICLINE 1,5 plug-in system secured by a screw locking mechanism for mounting, and packaged in cardboard.
