Phoenix Contact 1952432 PCB connector FMC 1,5/19-ST-3,5
Normally In Stock
Code: 723362
Phoenix Contact FMC 1,5/19-ST-3,5 - PCB connector, 19 Positions, 3.5 mm, 160 VAC, 8 Amp, Cu alloy - 1952432
Condition: New
Usually ships Same Day or Next Day$22.73
Sale Price
$18.94
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1952432 The PCB connector, with a nominal cross-sectional area of 1.5 mm² and a green color, is rated for 8 A of current and has a maximum allowed voltage of 160 V. It features a socket connection style, with 19 potentials, and uses a push-in spring connection method. The pitch between connections is 3.5 mm, and it is compatible with the FMC 1,5/ST product range. This connector does not require locking or mounting, as it is packaged in cardboard.
Specifications
Connector Color
Green
Connector Amperage
8 Amp
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
3.5 mm
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Operation and conductor connection from one direction enable integration into front of device
