Phoenix Contact 5436128 PCB connector BCP-508F-19 GY
Normally In Stock
Code: 723357
Phoenix Contact BCP-508F-19 GY - PCB connector, 19 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 5436128
Condition: New
Usually ships Same Day or Next Day$14.94
Sale Price
$12.45
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5436128 The PCB connector has a nominal cross-sectional area of 2.5mm², with a signal gray color and a rated current capacity of 12A at a maximum voltage of 320V (III/2). The contact surface is made of tin (Sn) and uses a socket connection type, featuring 19 contacts across one row, consisting of 19 connections, all mounted on a single PCB. The product range includes the BCP-F series, with a pitch of 5.08mm, secured via screw connections with tension sleeves, and features an H1L Slotted Phillips recessed screw head.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
5.08 mm
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Screwable flange for superior mechanical stability
Allows connection of two conductors
