Phoenix Contact 5448983 The PCB connector features a pastel green color with a nominal cross-sectional area of 2.5 mm², supporting up to 12 A of current and rated at 320 V (III/2). The contact surface is made of Sn material, with a socket connection type. It has 19 potentials, one row, and 19 connections across its single row configuration. The connector is secured by screw connection with a tension sleeve and features an H1L Slotted Phillips recess for the screw head. Conductor/PCB connection direction is set at 0° degrees, while locking is achieved through a screw locking mechanism or a plug-in system known as BASICLINE 2,5. Mounting occurs via a screw flange, with packaging in cardboard for protection and distribution.
