Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 5452585 PCB connector BCP-508F-19 BK
Normally In Stock
Code: 723355
Phoenix Contact BCP-508F-19 BK - PCB connector, 19 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 5452585
Condition: New
Usually ships Same Day or Next Day$14.94
Sale Price
$12.45
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5452585 The PCB connector features a nominal cross-sectional area of 2.5 mm² and is colored black, with a rated voltage of 320 V and a maximum current of 12 A. It has a socket contact surface, uses Sn plating, and employs a screw connection method secured by a tension sleeve, with an H1L Slotted Phillips recessed screw head. The connector includes 19 potential channels, arranged in one row with nineteen positions, connections, and conductor/PCB interfaces.
Specifications
Connector Amperage
12 Amp
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
5.08 mm
Connector Color
Pastel Green
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Screwable flange for superior mechanical stability
Allows connection of two conductors
