Phoenix Contact 5435705 PCB connector BCP-500F-19 GY
Normally In Stock
Code: 723354
Phoenix Contact BCP-500F-19 GY - PCB connector, 19 Positions, 5 mm, 320 VAC, 12 Amp, Cu alloy - 5435705
Condition: New
Usually ships Same Day or Next Day$15.06
Sale Price
$12.55
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5435705 The PCB connector has a nominal cross-section of 2.5 mm² and is colored signal gray. It can handle a maximum current of 12 A and is rated for a voltage of up to 320 V. The contact surface is made of tin, and the connection type is a socket with screw connections secured by tension sleeves. There are 19 potential contacts along one row in a pitch of 5 mm, requiring 19 screws per connector. In its packaging, it includes a screw flange for secure mounting via screws.
Specifications
Connector Amperage
12 Amp
Connector Color
Black
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
5 mm
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Screwable flange for superior mechanical stability
Allows connection of two conductors
