Phoenix Contact 1975244 PCB connector FKCS 2,5/19-ST-5,08
Normally In Stock
Code: 723351
Phoenix Contact FKCS 2,5/19-ST-5,08 - PCB connector, 19 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 1975244
Condition: New
Usually ships Same Day or Next Day$21.73
Sale Price
$18.11
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1975244 A PCB connector with a nominal cross section of 2.5mm² features a green color and is rated for a maximum current of 12A at a voltage of up to 320V. The contact surface material is tin, and the connection method involves a push-in spring connection with no locking clip, utilizing a combicon system with a pitch of 5.08mm, suitable for mounting without additional components in cardboard packaging.
Specifications
Connector Amperage
12 Amp
Connector Color
Black
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Positions
19
Number of Connections
19
Sub Component
PCB Connector
Connector Pitch
5.08 mm
Features
Time saving push-in connection, tools not required
Clamping space opened by means of fixed screwdriver enables convenient conductor connection
Quick and convenient testing using integrated test option
Can be combined with the MSTB 2,5 range
