Phoenix Contact 1702013 The connector features a nominal cross-section of 6 mm2, has a black color and is rated for a nominal current of 32 A with a maximum voltage of 1000 V. The contact surface is Sn plated and uses a socket connection type with six potentials, arranged in one row across six positions. It includes six connections and falls within the PC 5/...-STF1-SH product range with a pitch of 7.62 mm, secured via screw connections with tension sleeves featuring H1L Slotted Phillips recesses. The conductor connects to the PCB at a 0° angle, does not require locking clips for securement, and is part of the COMBICON PC 5 plug-in system, exhibiting shielded electrical properties and utilizing a screw locking mechanism for mounting, packaged in cardboard.
