Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 5435271 PCB connector BCP-381F-18 GY
Normally In Stock
Code: 723342
Phoenix Contact BCP-381F-18 GY - PCB connector, 18 Positions, 3.81 mm, 160 VAC, 8 Amp, Cu alloy - 5435271
Condition: New
Usually ships Same Day or Next Day$14.77
Sale Price
$12.31
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5435271 The PCB connector in question has a nominal cross-sectional area of 1.5 mm² and is colored signal gray, with a rated current of 8 A and a maximum voltage of 160 V. It features a Sn contact surface and uses a socket connection method, comprising 18 potential pins arranged in one row of 18 positions. The connector's characteristics include a screw connection system with a tension sleeve, L-slotted screw heads, and a plug-in system from the BASICLINE 1,5 series.
Specifications
Connector Amperage
8 Amp
Connector Color
Black
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Connections
18
Number of Positions
18
Sub Component
PCB Connector
Connector Pitch
3.81 mm
Code: 723342
Phoenix Contact 5435271 PCB connector BCP-381F-18 GY
$14.77
Sale Price
$12.31
