Phoenix Contact 5452546 A PCB connector features a 1.5 mm2 cross-sectional area with a black color and is designed to handle up to 8 A of nominal current while operating within a rated voltage of 160 V at an angle of 0 degrees relative to the conductor/PCB connection direction. The connector has 18 positions, a single row, and employs a screw connection method secured by a tension sleeve with a slotted L-shaped screw head, suitable for use in a BASICLINE 1,5 plug-in system that incorporates a screw locking mechanism for secure mounting via its flange-based attachment.
