Phoenix Contact 5434890 The PCB connector has a nominal cross-sectional area of 1.5 mm², with a signal gray color and a rated current of 8 A. It is designed to operate within a maximum voltage of 160 V (III/2) using a Sn contact surface. The connector features a socket connection type with 18 potential connections, arranged in one row across 18 positions. The connection method involves screwing onto a tension sleeve with an L slotted screw head, and the conductor is connected to the PCB at a 0° angle. The BASICLINE 1,5 plug-in system secures the connector in place via a screw locking mechanism, while it can be mounted using a screw flange on cardboard packaging.
