Phoenix Contact 5447832 PCB connector BCP-350F-18 GN
Normally In Stock
Code: 723335
Phoenix Contact BCP-350F-18 GN - PCB connector, 18 Positions, 3.5 mm, 160 VAC, 8 Amp, Cu alloy - 5447832
Condition: New
Usually ships Same Day or Next Day$14.58
Sale Price
$12.15
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 5447832 This PCB connector has a nominal cross-sectional area of 1.5 mm², with pastel green coloring and is rated for 160 V at 8 A. It features a contact surface made of tin (Sn) and uses a socket connection method with screw connection and tension sleeve, utilizing an L slotted screw head form. The connector has 18 positions, but only serves 18 connections and requires a BASICLINE 1,5 plug-in system for secure locking via screw mechanism, typically mounted using a screw flange in cardboard packaging.
Specifications
Connector Amperage
8 Amp
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Component
PCB
Number of Connections
18
Number of Positions
18
Sub Component
PCB Connector
Connector Pitch
3.5 mm
Connector Color
Signal Gray
