Phoenix Contact 5452527 The PCB connector has a cross-sectional area of 1.5 mm² and is colored black, with an allowed current of 8 A and a maximum rated voltage of 160 V. The contact surface uses tin and features a socket connection, accommodating 18 potential pins arranged in one row across 18 positions. This connector is part of the BCP-F product range, has a pitch of 3.5 mm, and connects using a screw method with tension sleeve, L-slotted screw head, and conductor to PCB orientation at 0 degrees. It utilizes the BASICLINE 1,5 locking system, can be mounted via a screw flange, and is packaged in cardboard.
