Phoenix Contact 5452192 A PCB connector has a nominal cross-section of 1.5mm², is colored black and has a maximum current rating of 8A with an operating voltage range of 160V. It features a Sn contact surface and socket connection type with 18 potential pins arranged in one row, across 18 positions, resulting in 18 connections. This connector falls within the BCP product range, has a pitch of 3.5mm and is secured via screw connections with tension sleeves, following an L-slotted screw head design, allowing for conductor-to-PCB connection at 0° angles and utilizing the BASICLINE 1.5 plug-in system, while lacking locking mechanisms and mounting options, packaged within cardboard.
