Phoenix Contact 1853049 PCB connector TMSTBP 2,5/ 5-ST-5,08
Normally In Stock
Code: 722642
Phoenix Contact TMSTBP 2,5/ 5-ST-5,08 - PCB connector, 5 Positions, 5.08 mm, 320 VAC, 12 Amp, Cu alloy - 1853049
Condition: New
Usually ships Same Day or Next Day$11.89
Sale Price
$9.91
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1853049 The PCB Twin plug features a nominal cross-sectional area of 2.5mm² with a green color, designed for a nominal current of 12A and rated voltage of 320V. Characterized by a socket contact connection type and five potential connections, it has one row and five positions with ten connections overall. This plug is part of the TMSTBP 2,5/...-ST product range, with a pitch of 5.08mm, utilizing a screw connection method with tension sleeve, featuring an L-slotted screw head and conductor/PCB connection direction at 0° degrees. The locking clip is optional, and it does not require any mounting or packaging; instead, it comes packed in cardboard to facilitate easy loop-through connections between modules.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
Cu Alloy
Manufacturer
Phoenix Contact
Number of Positions
5
Number of Connections
10
Component
PCB
Sub Component
PCB Plug
Connector Pitch
5.08 mm
Features
Well-known connection principle allows worldwide use
Potentials can be easily looped through – ideal for BUS applications
Quick and convenient testing using integrated test option
Allows connection of two conductors
