Phoenix Contact 2905652 Base element Type 2 surge protection base element
Phoenix 2905652 Base element Screw connection,Biconnect terminal blocks Type 2 surge protection base element Surge Protection
Normally In Stock! Order now!
Condition: New
Usually ships Same Day or Next Day (MUST BUY IN PACKS OF 12)
Price: $75.00
Sale Price:
$62.40
Base element for type 1/2 arresters from the VALVETRAB MS T1/T2 product range, with remote indication contact. Version: 1-channel
| Specifications | |
| Fault Warning | Optical |
| Fault Warning | remote indicator contact |
| Max Discharge Capacity | 5 A (70°C) |
| Combined Surge | 6 kV (3 kA) |
| Manufacturer | Phoenix Contact |
| Connection Method | Screw connection |
| Maximum Continous Voltage | 150 Volt |
| Surge Protector Type | Interference filters |
| Nominal Discharge Current | 3 kA |
- DIN rail mounting
- Plug-in direction parallel to the conductor axis
- Versions with and without floating remote indication contact
- Rack-mount 2U panel applications
- Accepts Type 1 and Type 2 VAL-MS plugs
- Coding when protective plug is inserted for the first time
Customer Reviews
0.0
All Reviews
Phoenix 2905652 CAD data International.dxf
Phoenix 2905652 CAD data International.pdf
Phoenix 2905652 CAD data International.stp
Phoenix 2905652 Flyer English.pdf
Phoenix 2905652 Manufacturers declaration English.pdf
Phoenix 2905652 Manufacturers declaration International.pdf
Phoenix 2905652 Package Slip International.pdf
Phoenix 2905652 Software International.zip
Phoenix 2905652 Surge Protection English.pdf
Phoenix 2905652 Tender Text English.zip
