Phoenix Contact 2702141 Communication module IB IL RS 485-ECO
Normally In Stock
Code: 71176
IB IL RS 485-ECO Phoenix 2702141 I/O component Inline Input,Output,Terminal RS-485 500 kbps Spring-cage connection,Inline data jumper PLC & IO
Condition: New
Usually ships Same Day or Next Day$402.19
Sale Price
$335.16
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2702141 The specified inline communication terminal features a RS-485 interface and is designed for process data communication with a local bus transmission speed of 500 kilobits per second, providing an IP20 level of protection against environmental factors, and includes the convenience of an inline connector.
Specifications
PLC & IO Network Interface
Inline Local Bus
PLC & IO Transmission Speed
500 Kbps
PLC & IO Degree of Protection
IP20
PLC & IO Connection Method
Inline Data Jumper
PLC & IO Connection Method
Spring-Cage Connection
PLC & IO Type
Inline
Manufacturer
Phoenix Contact
Component
I/O Component
Features
Number of data bits, stop bits and parity can be set
Data is transmitted in transparent mode
Transmission speed can be set up to 38400 bps
One serial input and output channel in RS-485 format
Parameterization and data exchange via process data
Downloads
Phoenix 2702141 Application Note English.pdfPhoenix 2702141 CAD data International.dxfPhoenix 2702141 CAD data International.pdfPhoenix 2702141 CAD data International.stpPhoenix 2702141 Configuration software International.zipPhoenix 2702141 Data Sheet English.pdfPhoenix 2702141 Device Description English.zbcPhoenix 2702141 Function Module International.msiPhoenix 2702141 Manual English.pdfPhoenix 2702141 Manufacturers declaration English.pdfPhoenix 2702141 Manufacturers declaration International-2.pdfPhoenix 2702141 Manufacturers declaration International.pdfPhoenix 2702141 Tender Text English.zipPhoenix 2702141 Various English.pdf
