Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 642073
Phoenix Contact 1582539 Conductor connector QPD CW 3PE2,5 2X9-14 BK
Normally In Stock
Phoenix Contact QPD CW 3PE2,5 2X9-14 BK Panel feed-through - 4 Positions, Black - 1582539
Condition: New
Usually ships Same Day or Next Day*NON-CANCELLABLE, NON-RETURNABLE*
$26.87
Sale Price
$22.39
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1582539 A cable connector panel feed-through, featuring a two-sided design with a QPD nut, is available in black and comes with three to four positive position options. The product accommodates cable diameters ranging from 9 millimeters to 14 millimeters, supporting currents of up to 20 amps at voltages of 630 volts per square millimeter.
Specifications
Connector Color
Black
Component
Panel Feed-Through
Manufacturer
Phoenix Contact
Number of Positions
4
Features
Innovative and time saving - QUICKON fast connection for time saving of up to 80 % for on-site connection
Robust throughout: housing with IP68/IP69K and IK07 protection for a wide range of applications
Safer connection with mechanical coding to protect against mismatching, and touch-proof protection in accordance with DIN EN 0105
Easy and safe - with the cable connector, you can repair or extend cables quickly, in combination with the connector as well as the coupling connection
Code: 642073
Phoenix Contact 1582539 Conductor connector QPD CW 3PE2,5 2X9-14 BK
$26.87
Sale Price
$22.39
