Code: 625759
Eaton ES2T2R1GF1P Elevator Control Switch - 60 Amp, NEMA 4, Single Pole, 208 VAC
Normally In Stock
Eaton ES2T2R1GF1P Elevator Control Switch - 60 Amp, NEMA 4, Single Pole, 208 VAC
Condition: New
Usually ships Same Day or Next Day*NON-CANCELLABLE, NON-RETURNABLE*
$12599.02
Sale Price
$10499.18
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton ES2T2R1GF1P - elevator control switch, 120 Vac coil fire safety interface relay, single-pole fire alarm voltage monitoring relay, green pilot light, no neutral lug, 60 A, NEMA 4, #14-#2 Al or Cu, 208 V - Class J Fuses not included, Contact factory for dimensions for NEMA 4 enclosure, Optional neutral lug size same as line and load. - 120 Vac coil fire safety interface relay, single-pole fire alarm voltage monitoring relay, green pilot light, no neutral lug
Specifications
Poles
Three Pole
Enclosure NEMA Rating
NEMA 4
Manufacturer
Eaton
Disconnect Enclosure Height
29.62 In
Voltage
600 VAC
Current
600 Amp
Disconnect Enclosure Width
16.35 In
Enclosure Disconnect Type
Elevator Control Switch
Disconnect Enclosure Depth
11.18 In
Features
Offers shunt trip capability, voltage monitoring, selective coordination and fire safety signal interface
Includes a key test switch for testing the shunt-trip circuit
Handle can be locked in the “OFF” position and accommodate a maximum of three padlocks
Completely assembled for quick installation, eliminating the labor and time needed to assemble individual components
Ensures maximum safety as the enclosure does not expose energized parts when the disconnect switch is manually turned to the OFF position during maintenance or shutdown service
Mechanically interlocked auxiliary contact for hydraulic elevators with battery backup
Easy to meet code requirements for selective coordination in a fully fused system
