Dwyer AFS-231 Adjustable Flow Switch
Normally In Stock
Code: 570858
Dwyer AFS-231 - Adjustable flow switch for gases, 18 AWG, 24" polymeric lead wires, brass piston, brass housing.
Condition: New
Usually ships Same Day or Next Day$1599.26
Sale Price
$1332.72
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer AFS-231 is an adjustable flow switch suitable for compatible gases or liquids. It has a temperature range of -20 to 300°F (-29 to 149°C) and an accuracy of ±10% of setpoint. This switch has a maximum pressure limit of 1000 psi (68 bar) and a switch type of SPDT. It requires 18 AWG, 24" (61 cm) polymeric lead wires for electrical connection and has a setpoint adjustment range of 0.5 to 20 GPM (1.9 to 75.7 LPM) for liquids and 1.0 to 75 SCFM (28 to 2124 LPM) for gases at 5 psig.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
(Instrument-Sensor) Measurement Accuracy
10%
Component
Flow Switch
(Instrument-Sensor) Type
Adjustable Flow Switch
(Instrument-Sensor) Temperature Range
-20 - 300°F/-29 - 149°C
(Instrument-Sensor) Temperature Range
-20 - 225°F/-29 - 107.2°C
Manufacturer
Dwyer Instruments
Features
Externally adjustable flow set point
Offers a number of flow settings at pressures up to 1000 psig, with low pressure drop and precise repeatability
