Dwyer SVP-2 Proportioning Solenoid Valve
Normally In Stock
Code: 570597
Dwyer SVP-2 - Proportioning solenoid valve, orifice 0.040" (1.02 mm), Cv of 0.033, max. flow 27.5 SCFH (13 LPM) air, max. flow rate 6.4 GPH (400 cc/m) water.
Condition: New
Usually ships Same Day or Next Day$977.12
Sale Price
$814.27
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer SVP-2 Proportioning Solenoid Valve is a reliable and versatile component. It can handle a wide temperature range from -40 to 174°F (-40 to 79°C) and is compatible with various gases. With a 1/4" compression fitting, it offers a pressure limit of 500 psig (34.45 bar) and a maximum differential pressure of 50 psid (3.45 bar). The valve, which operates at 0-24 VDC and consumes 400 mA, is normally closed and has a durable construction with 316 and 416 stainless steel and Viton® o-rings.
Specifications
(Instrument-Sensor) Application
Gas
Component
Solenoid Valve
Sub Component
Proportioning Solenoid Valve
(Instrument-Sensor) Temperature Range
Process: -40 - 174°F/-40 - 79°C
(Instrument-Sensor) Temperature Range
Ambient: -40 - 130°F/-40 - 54°C
Manufacturer
Dwyer Instruments
Features
The Series SVP is a low cost, uniquely designed solenoid valve which controls or regulates flow in proportion to a variable voltage input
While most solenoid valves simply provide on/off service, this unit adds a totally new dimension to solenoid valve performance
Reacting to a 0-24 VDC input signal, the valve opens in proportion to the voltage applied, delivering just the right amount of flow needed
Compatible with a wide range of gases and liquids, this unit provides the solution to even the most demanding applications like process control, chemical mixing, high tech manufacturing and laboratory testing
Another quality feature of this valve is its tight shut-off (NC) when de-energized.
